Sound Magus DK1200 Class D AMP - 1000 RMS

Model: Sound Magus DK1200 Class D AMP - 1000 RMS
Condition: Brand New

1 ohm load stable
Double Side PCB and SMD components
Adjustable Input level, LPF, Subsonic function
Advanced short circuit, overload, over heat protection
Advanced clip limit / thermal power limit function
Optional remote controller

Specifications

• Product Dimensions : 255(Length)140(Width)54(Height)

• Brand : Sound Magus

• Input Level : 0.2-5 V

• 1200W x 1RMS(1 OHM, 14.4)

• 600W x 1RMS(2 OHM, 14.4)

• 400W x 1RMS(4 OHM, 14.4)

• Frequency Response : 10-220 Hz

• LPFLPF : 40-220 Hz

• Sub Sonic Filter (HPF) : 10-50 Hz

• THD at 4Ohm Load 30% Rated Power : <0.3%

• S/N Ratio : >80dB

• Best Efficiency @4ohm : >80%

• Minimum Load : 1 Ohm

• Optional Remote : YES

• Low Voltage Protection : Yes, Protect

• Short Circuit Test @ Max Power : Pass

• Overheat Protect Temperature : Protect at 80/176F

• Components & PCB : SMD Parts/Double-side FR-4

Note: Manufacturers warranty is void if damaged due to failure in installation or power surge. Professional installation is required. For warranty, invoice/certificate from installer is mandatory.
